P-660R-Tx v2 Series User’s Guide

Chapter 12 Maintenance

111

Figure 55 Firmware Upgrade

The following table describes the labels in this screen.

Note: Do not turn off the ZyXEL Device while firmware upload is in progress!

After you see the Firmware Upload in Process screen, wait two minutes before logging into
the ZyXEL Device again.

The ZyXEL Device automatically restarts in this time causing a temporary network
disconnect. In some operating systems, you may see the following icon on your desktop.

Figure 56 Network Temporarily Disconnected

After two minutes, log in again and check your new firmware version in the System Status
screen.

Table 31 Firmware Upgrade

LABEL

DESCRIPTION

File Path

Type in the location of the file you want to upload in this field or click Browse ... to find it.

Browse...

Click Browse... to find the .bin file you want to upload. Remember that you must

decompress compressed (.zip) files before you can upload them.

Upload

Click Upload to begin the upload process. This process may take up to two minutes.

Reset

Click this button to clear all user-entered configuration information and return the ZyXEL

Device to its factory defaults. Refer to

Section 2.2 on page 36

.
