AIR FLOW DATA
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
060B12 080B12 Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1343 865 1320 882 A B
1116 727 1093 755 B B
1235 791 1203 810 A A
1026 661 1001 693 B A
1079 709 1080 730 A C
889 590 880 641 C B
900 599 910 642 B C
787 531 803 585 D B
814 542 836 597 C A
712 490 738 557 D A
725 499 749 561 C C
641 456 682 529 D C
080C16 100C16 Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1787 1171 1818 1192 A B
1503 987 1545 1030 B B
1620 1053 1661 1083 A A
1405 914 1427 936 B A
1462 964 1497 991 A C
1217 785 1234 819 C B
1245 818 1265 832 B C
940 608 977 648 D B
1091 702 1116 728 C A
852 551 884 572 D A
983 626 1019 666 C C
764 544 791 519 D C
100C20 120D20 Jumper Settings
High Low High Low COOL Tap ADJ Tap*
2019 1290 2006 1397 A B
1790 1174 1687 1131 B B
1818 1195 1845 1282 A A
1630 1068 1552 1050 B A
1649 1082 1694 1157 A C
1269 848 1502 1011 C B
1432 956 1400 944 B C
1078 704 1365 922 D B
1169 770 1364 931 C A
986 638 1232 808 D A
1062 685 1225 808 C C
866 576 1117 718 D C
HIGH / LOW HEAT CFM
060B12 80B12 Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1364 843 1433 945 A Any
1253 745 1320 887 B Any
1102 660 1223 840 C Any
1014 607 1134 768 D Any
80C16 100C16 Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1684 1095 1795 1171 A Any
1542 1011 1585 1047 B Any
1426 927 1420 929 C Any
1289 832 1201 785 D Any
100C20 120D20 Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
2194 1417 1937 1323 A Any
1999 1290 1757 1199 B Any
1799 1182 1594 1062 C Any
1614 1062 1429 957 D Any
All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6” w.c.
static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external static
pressure is not recommended.
NOTE: At some settings, LOW COOL and/or LOW HEAT airflow may be lower that what is required to operate an airflow switch on certain models of electronic air clean-
ers. Consult the instructions for the electronic air cleaner for further details.
* The ADJ “D” tap should not be used.
