ES-3100 Series Switch Support Notes
All contents copyright (c) 2006 ZyXEL Communications Corporation.
80
Configuration via CLI [ES-3124]
Connect the Switch Console port with your PC or Notebook.
1. Open your Terminal program.(Ex, Hyper Terminal in Windows System)
2. Make sure that your port settings are
bps:9600
Data bits:8
Parity: None
Stop bits:1
Flow control: None:
3. After you connected successfully, give the correct user name and
password.
4. Put “en” or “enable” to go into the privileged mode. Then put “config” to go
into the configuration mode.
Issue the following commands to setup your Switch in this scenario.
To Setup VLAN 101:
vlan 101
name Data
normal 2-27
fixed 1,28
forbidden ""
untagged 1
exit
To Setup VLAN 102:
vlan 102
name Data
normal 1,3-27
fixed 2,28
forbidden ""
