VID:102 (port 6,7,8,9,10,"25 TAG")
VID:103 (port 11,12,13,14,"25 TAG")
VID:104 (port 15,16,17,18,"25 TAG")
VID:105 (port 19,20,21,23,22"25 TAG)
Clients in same VLAN on both switches can communicate each other.
PVID:
z
Set PVID on switch 1
Port 1, 2, 3 : 101
Port 4, 5, 6 : 102
Port 7, 8, 9, 10 : 103
Port 23, 24: 104
Port 11, 12, 13, 14: 105
Port 15, 16, 17: 106
Port 18, 19, 20, 21: 107
port 25: PVID=any
z Set PVID on switch 2:
Port 1, 2, 3, 4 : 101
Port 6, 7, 8, 9, 10, : 102
Port 11, 12, 13, 14, : 103
Port 15, 16, 17, 18: 104
Port 19, 20, 21, 22, 23: 105
Port 25:PVID=any
