About Link 1000 Settings
23
Series Connection If you are using a single battery bank that
consists of two or more batteries connected in series, use the
Ah capacity of one battery. For example, if two Trojan T-105
6 volt golf cart batteries are connected in series, use the
factory default 200 Ah for capacity.
Changing the Battery Capacity Setting
To change the Battery Capacity setting:
1. Press SET until
SEL appears in the display.
2. Press SEL three times. The LED comes on and
200
(the default) appears.
3. Press SET and hold it until the value you want appears.
Changing the Battery Type Setting
Change the Battery Type setting if you are not using flooded
lead-acid batteries. For details about battery types, see
page 33 .
To change the Battery Type setting:
1. Press and hold SET until
SEL appears.
2. Press SEL until
Func F10 appears.
3. Press SET to select one of the following battery types: 0
(liquid cell), battery type 1 (gel cell, standard), battery
type 2 (gel cell, fast charge), or battery type 3 (AGM –
Absorbed Glass Mat).
Battery Capacity
(Ah) Incremental step
in Ah
20 to 40 1
40 to 100 5
more than 100 20
Note: If you continue to hold SET , the display scrolls faster
after four increments. If you go past your battery’s capacity,
you have to scroll to 1980Ah. The display then rolls over and
begins scrolling up from 20Ah.
