Installing the Link 1000
15
Wiring the Terminal Block
Prepare for wiring by following these guidelines:
• Pull the wires and the phone cable through the opening in
the mounting plate (unless you are running them down
from the bottom of the mounting plate).
• Prepare the wires by giving each:
• A clean cut
• A clean strip
• A tightly twisted end
• Loosen the terminal block screws, pry the wire clamps
open with a paper clip, and insert the wires using needle-
nose pliers.
• Tighten the screws firmly, but do not overtighten.
To wire the terminal block:
• Insert the wires in the terminal block following the
sequence shown below.
Note
:
Terminal 1 is next to the phone cable jack.
Terminal Wire Color and Function
1 Black. Control panel negative to the large bolt on the
load side of the shunt.
2 Green. Sense lead to the load side of the shunt.
3 Orange. Sense lead to the battery side of the shunt.
4 Blue. Voltage sense lead to the positive battery
terminal.
5 Red. Power lead to the positive battery terminal.
6 Violet. Voltage sense lead to the positive battery
terminal. Connect this lead if you are monitoring the
voltage of a second (starting) battery.
7 Not used
8 Not used
