P-660HW-T v2 User’s Guide
Chapter 2 Introducing the Web Configurator 49
2.4.3 Status: Any IP Table
Click the Any IP Table hyperlink in the Status screen. The Any IP table shows current read-
only information (including the IP address and the MAC address) of all network devices that
use the Any IP feature to communicate with the ZyXEL Device.
Figure 9 Status: Any IP Table
The following table describes the labels in this screen.
2.4.4 Status: WLAN Status
Click the WLAN Status hyperlink in the Status screen to view the wireless stations that are
currently associated to the ZyXEL Device.
Bandwidth Status Use this screen to view the ZyXEL Device’s bandwidth usage and allotments.
Packet Statistics Use this screen to view port status and packet specific statistics.
Table 4 Status Screen
LABEL DESCRIPTION
Table 5 Status: Any IP Table
LABEL DESCRIPTION
# This is the index number of the host computer.
IP Address This field displays the IP address of the network device.
MAC Address This field displays the MAC (Media Access Control) address of the computer with the
displayed IP address.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Refresh Click Refresh to update this screen.
