Front panel leds for omni 56k – ZyXEL Communications 56K User Manual
Page 16
User's Guide for ZyXEL Omni 56K and Omni 56K Plus Modems
2-2
Front Panel LEDs for Omni 56K
LED
Function
description
V.90
V.90 mode
ON: connection V.90 mode
OFF: none V.90 mode
OH
Hook Status
ON: off hook
OFF: on hook
DATA
Data
transmission
ON: data transmission
OFF: no data
MR
Modem Ready ON: modem is ready
OFF: modem is not ready
Table 2.
Front Panel LEDs for Omni 56K
