P-2301/2R-P1C / P-2301RL-P1C User’s Guide
40
7 Wall Mounting Instructions
Do the following to hang your ZyXEL Device on a wall.
1 Select a position free of obstructions on a sturdy wall.
2 Drill two holes for the screws. Make sure the distance
between the centers of the holes, and the size of screws
you use, match what is listed in section
8 on page 41 .
"
Be careful to avoid damaging pipes or cables
located inside the wall when drilling holes for the
screws.
3 Do not screw the screws all the way into the wall. Leave a
small gap of about 0.5 cm between the heads of the
screws and the wall.
4 Make sure the screws are snugly fastened to the wall.
They need to hold the weight of the ZyXEL Device with the
connection cables.
