weber FT 600 - Manual (Page 27)

27
Step 26
Reinstall front panel, control panel and burner
control knobs
You will need: control panel, front panel, and four
burner control knobs.
With the Weber logo to the left, slide front panel down
into place. Figure 38.
Figure 38
Figure 39
(a)
Figure 40
Push on the burner control knobs. Figure 40.
Pull igniter buttons up until they stay in the up position.
Place the control panel into the grooves on either side
of the front of the cooking box. Push the control panel
into place, using even pressure while pushing.
Figure 39 (a).
Use your fingers to lift the front edge of the control
panel slightly and set it into the recess on both sides of
the cooking box. Figure 39.
Front Panel
Control Panel
