weber FT 600 - Manual (Page 18)

Front edge of the
control panel
18
Step 13
Remove the control panel and the front panel
Take off all 6 burner control knobs.
Pull up on the ignition buttons until they stay in the up
position. Figure 17.
Put your fingers under the front edge of the control
panel and lift up and pull evenly toward you.
Figure 19 (a).
The control panel is separate from the front panel. The
control panel needs to be removed before the front
panel can be removed. Figure 18.
Pull the front panel up and out of the cooking box
assembly. Figure 20.
Figure 17
Figure 18
Figure 19
(a)
Figure 20
Burner control knobs
Ignition button
Front Panel
Control Panel
Front panel
Control
panel
Front
panel
