17
Figure 15
Figure 16
(a)
Flanges
Cooking box
assembly
Control
panel
Step 12
Add cooking box assembly
You will need: frame assembly and cooking box
assembly.
Note: This assembly takes two people to lift the
cooking box assembly into the frame.
Uncoil the hose.
Set the cooking box into the frame so the control panel
is under the top frame rail. Figure 15.
The cooking box assembly fits into place between the
two flanges in the back panel. The entire cooking box
assembly rests on the top frame rails. Figure 16 (a).
