Maintenance Instructions
LUBRICATION
48
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Tee Gearbox, Deck Oil * 1
4 Blade Drive Gearbox Oil * 2
5 PTO Shaft Guard Hinge Oil 1
6 Universal Joint Shaft Assembly Grease ** 1
7 Pivot Assembly, Tilt-Up Deck Grease 4
8 Deck Support Arm Socket Grease 2
9 Body Hinge Point Oil 2
10 FSC Actuator Rod Pivot Pins Oil 2
11 FSC Lever Pivot Grease 1
12 FSC Lever Fork Grease 1
(Grease Slide Area)
13 (FSC) Friction Body Pivot Grease 1
14 Steering Lever Pivot Grease 4
15 Deck Roller Wheel Oil 2
16 Deck Support Arm Pivot Grease 2
17 Deck-to-PTO Coupling Grease 1
(Grease Slide Area)
18 Universal Joint Tube Assembly Grease ** 1
19 Universal Joint Quick Connect Grease 1
Spline (Grease Slide Area)
20 Parking Brake Lever Grease 1
21 Gear Axle Oil *** 2
22 Belt Tightener Pivot, Grease 1
Jackshaft Drive
23 Throttle Control Cable Ends Oil 2
24 Clutch Actuator Push Rod Grease 2
25 PTO Clutch Lever Pivot Grease 1
26 Belt Tightener Pivot, Grease 1
PTO Clutch
27 Brake Actuator Rod and Brake Oil 3
Band Pivot Pins (Clevis)
28 Brake Actuator Pivot Grease 1
29 Anti-Scuff Roller Wheel Oil 2
30 Catcher Hinge Point Oil 2
31 Rear Wheel Bearings Grease 2
32 Engine Oil Oil *** 1
33 Choke Control Cable Ends Oil 2
34 Belt Tightener Pivot, Grease 1
Blower Drive (GHS Model Only)
35 Belt Tightener Pivot, Grease 1
Ground Drive
36 PTO Gearbox Dipstick Oil *** 1
37 Hydrostatic Drive Oil *** 2
38 Choke Control Pivot Oil 1
39 Throttle Control Pivot Oil 1
40 Discharge Chute Hinge Oil 1
* Gearboxes are permanently lubricated and
sealed requiring no scheduled lubrication.
Oil level should be checked only when an oil
leak is noted. Refer to Mower Deck Gear-
box Lubrication in this section.
** Grease every eight (8) hours.
*** Refer to Gear Axle Lubrication, Engine
Oil, Tractor PTO Gearbox Lubrication, and
Hydrostatic Transmission Fluid in this sec-
tion.
NOTE: DGHS42 Tilt-Up Deck is shown for reference.
For other Deck Lubrication Points, Refer to
Deck and Carrier Frame
Illustrated Parts
Manual .
