Specifications
6
MODEL
MT 20.0 HP MT 25.0 HP
DRIVE BELTS
Engine PTO Walker P/N 8230 Walker P/N 8230
Jackshaft Drive Gates 3VX355
(or Walker P/N 6231) Gates 3VX355
(or Walker P/N 6231)
Ground Drive, Micro-V Walker P/N 7248 Walker P/N 7248
Blower (GHS Model) Gates 3VX280
(or Walker P/N 7234) Gates 3VX280
(or Walker P/N 7234)
GHS SYSTEM (Optional)
Blower 4 x 10 x 1/4 in. (10 x 25 x 1 cm)
Three-Blade Paddle Wheel
(Driven by Mower Engine) 4 x 10 x 1/4 in. (10 x 25 x 1 cm)
Three-Blade Paddle Wheel
(Driven by Mower Engine)
Blower Brake Band Brake (Works in Combi-
nation with PTO Clutch, Stops
Blower within Five (5) Seconds
of PTO Disengagement) Band Brake (Works in Combi-
nation with PTO Clutch, Stops
Blower within Five (5) Seconds
of PTO Disengagement)
Max. Blower Speed 3600 RPM 3600 RPM
Grass Catcher Capacity 65 Gallons (246 liters)/
7.0 Bushels 65 Gallons (246 liters)/
7.0 Bushels
Optional Grass Catcher
Capacity 76 Gallons (335 liters)/
9.5 Bushels 76 Gallons (335 liters)/
9.5 Bushels
Full Signal Oscillating Vane Switch
Mounted on Grass Delivery
Spout Triggers Horn Signal Oscillating Vane Switch
Mounted on Grass Delivery
Spout Triggers Horn Signal
Powerfil
®
Oscillating Delivery Spout
Driven by 12 Volt Electric
Gearmotor Spreads Material
throughout Interior of Catcher
@ 25 Cycles/Minute Oscillating Delivery Spout
Driven by 12 Volt Electric
Gearmotor Spreads Material
throughout Interior of Catcher
@ 25 Cycles/Minute
SEAT Contour-Molded, with Nylon
Backed Vinyl Cover and
Integral Foam Cushion Contour-Molded, with Nylon
Backed Vinyl Cover and
Integral Foam Cushion
FRAME/BODY CONSTRUCTION
Frame All Welded Unitized Steel
Chassis All Welded Unitized Steel
Chassis
Body 14 Gauge Steel 14 Gauge Steel
Deck 11 Gauge Steel 11 Gauge Steel
GHS Catcher and Chutes Molded Cross-Linked
Polyethylene (UV Stabilized)
Molded Cross-Linked
Polyethylene (UV Stabilized)
NOTE: The manufacturer reserves the right to make changes in specifications shown herein at any time
without notice or obligation.
