TECHNICAL SPECIFICATIONS
SGJ32 86037680 01/03/07
3-1
ITEM DIMENSION/CAPACITY
Nominal power
2.9 kW
Rated Voltage 36 Volts DC
Rated Amperage 80 amps
Batteries 6 x 6 Volt 250-335 AH @20 hr. rate
Scrub Brush Motors 2 x 1.0 HP (746 W)
Vacuum Motor(s) 1 x .75 HP (560 W) Standard, second motor
optional
Propelling Motor 1.3 HP (932 W)
Mass (GVW) 1810 lbs (820 kg)
Weight empty without batteries 790 lbs (360 kg)
Solution Control Gravity feed, fully variable with automatic
shut off in neutral
Solution tank capacity 30 gal (115 L)
Recovery tank capacity 30 gal (115 L)
Scrub brush diameter for 32 in. (81 cm) disk scrub head 16 inch (40.6 cm)
Scrub brush pressure 0-225 lbs (0-1000N)
Scrub brush speed 300 rpm
Tires 12 in. (30.5 cm) Solid Scrubber Compound
Foundation Pressure 108 lbs./in² (745 kPa)
Maximum Speed 4.1 miles/hour (6.5 Km/hour)
Coverage with 32 in. (81 cm) scrub head 48,840 ft²/hr @ 3.7 mph with 2 in. overlap
Frame Construction Powder coated steel
Brakes Self centering mechanical 7 in. (17.7 cm)
disc with hand lock parking brake
Minimum aisle u-turn width 32 in. (81 cm) disk scrub head 66 inches (168 cm)
Maximum rated climb and descent angle 7.5 degrees
