86037680p4-1, Maintenance – Windsor Saber Glide 10052530 User Manual
Page 24
MAINTENANCE
SGJ32 86037680 01/03/07
4-1
1. Batteries
2. Squeegee Adjustment
3. Side Squeegee Adjustment
4. Scrub Brushes
5. Vacuum Filter
6. Float Switch
7. Solution Strainer
8. Brake
9. Steering Chain Tensioner
10. Vacuum Motor
11. Brush Motor
12. Traction Motor
13. Fuse
14. Circuit Breaker
15. Squeegee Lift Actuator
16. Scrub Lift Actuator
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
4
