The signal descriptions in Table 3-2 apply to the connector on the scanner and are for
reference only.
Table 3-2. Scanner Signal Pin-outs
Pin USB Keyboard Wedge
1 Jump to Pin 6 Reserved
2 Power Power
3 Ground Ground
4 Reserved KeyClock
5 D + TermData
6 Jump to Pin 1 KeyData
7 D - TermClock
8 Reserved Reserved
9 Reserved Reserved
10 Reserved Reserved
