1-4

Wasp WPS100 Product Reference Guide

Connecting Power (if required)

If your host does not provide power to the scanner, you will need an external power
connection to the scanner:

1. Connect the interface cable to the back of the scanner, as described in

2. Connect the other end of the interface cable to the host (refer to your host manual

to locate the correct port).

3. Plug the power supply into the power jack on the interface cable.
4. Plug the other end of the power supply into an AC outlet.

Configuring Your Scanner

Configure your scanner using the bar codes included in this manual. Refer to

for information about programming your scanner using bar code menus.

The scanner supports Keyboard Wedge and USB interfaces. Each host specific chapter
describes how to set up each of these connections.

Removing the Interface Cable

To remove the interface cable:

1. Unplug the installed cable’s modular connector by depressing the connector clip

and gently pulling back.

2. Follow the steps for

cable.
