SUGGESTED SPARE PARTS
86011370 NUWAVE 10/13/07 5-23
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86216120 12543 BRUSH, 25.5 X 4.0 OD, FRONT
2 86216110 12540 BRUSH, 25.5 X 4.0 OD, REAR
3 86215310 11056 BELT, TIMING, 5MM X 15MM X 575
4 86291380 - BELT, 290J6, MICRO-V
5A 86215670 140839 BREAKER, 8A VDE CIRCUIT 120V ONLY
5B 86215710 141046 BREAKER, 5A VDE CIRCUIT 230V ONLY
6 86007130 72128 SWITCH, DPDT 2-POSITION ROCKER
7 86135320 140687 BRUSH SET 120V & 230V
8 86215090 140949 BAG, PAPER WIDE AREA VAC
9 86224630 730380 SPRING, BRUSH CLIP
10 86012790 - SHAFT ASM, BRUSH DRIVE
11 86217850 34459 FILTER, VAC CHAMBER
12 86292930 - GASKET, BASE PLATE
13 86218290 35382 GASKET, CONSOLE, HANDLE
14 86238080 36261 GASKET, 1 W X 5/8 FOAM, M
15 86238070 36260 GASKET, 1 W X 5/8 FOAM, F
16 86218200 35372 GASKET, FITTING ACCESSORY PORT
17 86218190 35371 GASKET, CONSOLE, TUBE
18 86003780 35171 GASKET, ACCESSORY PORT
19 86218310 36251 GASKET, 5.50OD X 3.85ID X .06
