COVER
86011370 NUWAVE 11/05/08
5-8
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86217470
270800
1
COVER, ACCESSORY PORT
2 86218300 36250 1
GASKET, ACCESSORY PORT
COVER
3
86173330
87513
5
WASHER, M5, FLAT, ISO7093, SS
4
86293360
-
1
SCR, M5X12 GR 8.8, PLT
5
86293390
-
2
SCR, M5X15 SHCS, GR 10.9 BLK
6
86173350
87515
2
WASHER, M5, FLAT, ISO7089, SS
7
86008650
80604
6
COTTER, 1/4” RING
8
86222620
66891
1
PIN, 5MM DIA X 85MM L
9
86216030
620119
1
BRKT, ACCESSORY PORT HINGE
10
86225080
72152
1
SWITCH, 125 VAC SP NC ROLLER
11 86173110 70936 2
SCR, M3X16, BSHCS, ISO7380,
SST
12
86225630
75478
1
VACUUM LID, TRIM
13 86218200 35372 1
GASKET, FITTING ACCESSORY
PORT
14
86217880
34458
1
FITTING, ACCESSORY PORT
15
OPEN - -
-
16
86295530
-
1
NUT, HEX, M3, PLT
17
86274340
70179
6
SCR, M6 X 16 PH
18
86215160
141059
1
BASKET, FILTER BAG MOLDED
19
86238080
36261
2
GASKET, 1 W X 5/8 FOAM, M
20
86238070
36260
2
GASKET, 1 W X 5/8 FOAM, F
21
86222640
66893
2
PIN, 6 MM DIA X 60 MM LG
22 86223780 70896 2
SCR, M4X8, SET, ISO4029, CP,
BLK
23
86293420
-
4
SCR, M8X20 FHCS BR 10.9 BLK
24 86218930 41569 2 HINGE,
LID
25
86222640
66893
2
PIN, 6 MM DIA X 60 MM LG
26
OPEN - -
-
27 86224770 739989 1 SPRING,
TORSION
28
86222960
62866
1
PLATE, ACCESSORY PORT
29
86014530
-
4
SCR, KA50X16, PT, WN1412,PL
30
86216750
20098
1
CLAMP, WORM GEAR 40-64MM
31
86219120
39736
1
HOSE, 2.0 ID X 15.75L, 3.5:1
32
86311920
-
1
SNAP RING, 50MM ID, BLACK
-
86215090
140949
-
BAG, PAPER WIDE AREA VAC
NOT SHOWN
