BRUSH DECK
86011370 NUWAVE 11/01/07
5-2
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86293390
-
8
SCR, M5 X .8 X 15 SHCS GR 10.9
BLK
2
86137300
87084
8
WASHER, M8 FLAT DIN125A PLT
3
86173350
87515
5
WASHER, M5, FLAT, ISO7089, SS
4
86290110
-
1
NOZZLE, VACUUM, DECK
5
86218140
35366
2
GASKET, VAC NOZZLE
6
86270830
57023
5
NUT, 5/16-18 HEX NYLOCK SS
7
86010670
87029
5
WASHER, 5/16 FLAT SS
8 86292460
-
2
WELMENT, DECK LEVELING
BRKT
9 OPEN
-
-
-
10
86010720
87086
4
WASHER, M10 X 30 PLTD
11
86295960
-
4
SCR, M10 X 20 HHMS GR 8.8 PLT
12
86293380
-
4
SCR, 5/16-18 X 3/4 CARR GR 10.9
13
86012780
-
1
PULLEY ASM, 5MM HTD 22T
14
86277130
70795
1
SCR, 5/16 X 1.00 CARRAGE SS
15
86293400
-
10
SCR, M5X12 SHCS GR 10.9 PLT
16
86293200
-
1
ASSY, JACK SHAFT DRIVE
17
86215230
09161
1
BEARING, BRONZE FLANGED
18 86223520 67598 3
RING, 28MM INT SNAP
PHOSPHATE
19
86215530
140941
1
BRACKET, BELT TENSIONER
20
86279130
87083
1
WASHER, 5/16 SPLIT LOCK PLTD
21
86215310
11056
1
BELT, TIMING, 5MM X 15MM X 575
22
86223310
64116
1
PULLEY, 5MM HTD, 18T, 12.7ID
23
86223490
67468
2
RING, 10MM EXT SNAP, DIN 471
24
86222890
620118
1
PLATE, BRUSH DRIVE COVER
25 86172970 70911 4
SCR, M5X12, PHLP PHMS, ISO
7046, SS
26
86223320
64117
2
PULLEY, 32T, 5MM HTD
27 86223780 70896 10
SCR, M4X8, SET, ISO4029, CP,
BLK
28
86012790
-
2
ASSY, BRSH END CAP SHFT
29
86219400
41554
1
HOUSING, BRUSH DRIVE
30
86216120
12543
1
BRUSH, 25.5 X 4.0 OD, FRONT
31
86216110
12540
1
BRUSH, 25.5 X 4.0 OD, REAR
32
86216750
20098
1
CLAMP, WORM GEAR 40-64MM
33
86291140
-
1
PULLEY, MICRO-V, 1.125 OD
34
86217810
32061
1
EXTRUSION, DUAL BRUSH DECK
35 86219410 41555 1 HOUSING,
BRUSH RELEASE CLIP
36
86293230
-
2
ASSY, BRSH END CAP SHFT
37 86172980 70912 2
SCR, KA50X10, PT OHS, WN1412,
PLTD
38
86224630
730380
2
SPRING, BRUSH CLIP
39
86295970
-
4
WASHER, M10 EXT STAR LOCK
40
86173330
87513
8
WASHER, M5 FLAT, ISO7093, SS
