601-137-0 pg 5-6 and 5-7, Control panel – Windsor NuWave NWIFE 10125340 User Manual
Page 27
CONTROL PANEL
86011370 NUWAVE 10/13/07
5-6
F
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86172640
57507
1
NUT, M8, NYLOCK, ISO7040, SST
2
86173300
87495
1
WASHER, M8, FLAT ISO7089, SST
3
86224730
73939
1
SPRING, COMP, 12MM OD X 12.7MM
4
86215410
140416
3
BOOT, CIRCUIT BREAKER MP/MB
5 86007130 72128 1
SWITCH, DPDT 2-POSITION
ROCKER
6 86225960 89503 1 WELDMENT,
ELECTICAL
PANEL
7
86005700
57104
2
NUT, 10-32 W/STAR
8
86221820
51467
1
LIGHT, INDICATOR, RED, 120VAC
9
86218960
41575
1
HOOK, UPPER, CORD
10
86223830
70927
1
SCR, M8X40, SHCS, ISO 4762, SST
11A
86217150
23733
1
CORD ASM, 14/3 SJT X 75’ YLW
11B
86217160
23734
1
CORD ASM, EURO 1.5 MM X 75 BLK
11C
86217170
23735
1
CORD ASM, AUST 1.5MM X 75 BLK
12A 86215670 140839 3 BREAKER,
8A
VDE CIRCUIT
120V ONLY
12B
86215710
141046
3
BREAKER, 5A VDE CIRCUIT
230V ONLY
13
86218290
35382
4
GASKET, CONSOLE, HANDLE
14
86276820
70740
3
SCR, 10-32 X 1/2 PTHMS BLK NP
15
86299320
-
1
LABEL, GROUND SYMBOL
230V ONLY
16
86010640
87016
1
WASHER, #10 LOCK EXT STAR SS
