WIRING DIAGRAM-120V
86011370 NUWAVE 11/01/07
5-20
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86266900
880095
1
WIRE, 5” BLK/14 76029 X 76029
2
86268400
88301
3
WIRE, 3” BLK/14 76029 X 76050
3
86218860
41579
1
HARNESS, MAIN VACUUM
4
86267290
880262
2
WIRE, 14” GRN/18 76008 X 76011
5
86268210
88205
2
WIRE, 15” GRN/18 76008 X 76008
6
86218850
41578
1
HARNESS, SWITCH VACUUM
7
86295540
-
2
WIRE, JUMPER, 130L X 14GA BLK
