FRAME
86011370 NUWAVE 11/01/07
5-12
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86274860 70311 18
SCR.
M8X20
HHMS
2
86137310
87098
18
WASHER, M8 SPLIT LOCK
3
86137280
87054
20
WASHER, M8 FLAT DIN125A PLT
4
86295660
-
1
WELDMENT, HANDLE BRACE
5
86295780
-
2
M8X40 HHCS GR 8.8 PLT
6
86226050
89279
2
WHEEL, 9.75” X 1.5”
7
86225730
87218
2
WASHER, M6 (20.5 ODX1.6T) PLT
8 86173310 87499 2
WASHER, SPRING LK, M6,
DIN127B, SST
9
86293430
-
2
SCR, M6 X 16 HHMS GR 10.9 PLT
10
86219480
41567
2
HUBCAP, 9.75 WHEEL
11
86293440
-
4
SCR, M8X25 HHCS BR 8.8 PLT
12 86228840 09124 6
BEARING, FLANGED
.314IDX.502OD
13
86215890
140951
2
BRKT, SPRING ADJUST
14
86010720
87086
2
WASHER, M10 X 30 PLTD
15 86259400 87205 8
WASHER, THRUST .51 ID X 1
ODBRO
16
86224690
730438
2
SPRING, .718OD X 3.41L X .091W
17 86223810 70925 2
SCR, ADJUSTMENT DECK
SPRING
18
86196610
94045
6
NUT, M8 HEX NYLOCK
19
86216020
34461
1
BRKT, DECK LINGAGE, LEFT
20
86218430
36253
1
GUARD, BELT BRUSH DRIVE
21 86172980 70912 2
SCR, KA50X10, PT OHS, WN1412,
PLTD
22
86002340
18045
2
CASTER, 3.0 SWIVEL
23
86216010
34460
1
BRKT, DECK LINKAGE, RIGHT
24
86005700
57104
1
NUT, 10-32 W/STAR
25 86217980 89499 1 FRAME,
WELDMENT
26 86225970 89508 1
WELDMENT, HANDLE BRKT,
RIGHT
27 86225980 89509 1 WELDMENT,
HANDLE BRKT, LEFT
28
86010640
87016
1
WASHER, #10 EXT STAR LOCK SS
