TOOLS – HIGH PRESSURE WAND-OPTION
CMPS2 86305210 01/14/08
6-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86005580 56012 1 NIPPLE, 1/4 FPT QD
2 86240210 39641 1 HOSE, 1/8 MPT X 1/4 MPT X 7 L
3 86274410 70195 1 SCR, 10-32 X 1.25 PPHMS SS
4 86258950 84189 1 VALVE, 500 PSI W/ CLAMP
5 86240200 39640 1 HOSE, 1/8 MPT X 1/8 MPT X 38L
6 86200810 270-11 1 NIPPLE, 1/8 FPT QD FEM BRASS
7 86257680 02480 1 TOOL, ALUMINUM WAND
8 86270990 57090 1 NUT, 10-32 HEX NYLOCK SS
9 86041300 47432 REF KIT, HIGH PRESSURE WAND COMPLETE
10 86135760 38109 1 HANDLE GRIP ASSEMBLY 1.5”T
