VACUUM
CMPS2 86305210 04/23/08
5-16
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86237870 35270 1 GASKET, 5.0 OD X 2.38 ID X .25T
2 86002380 20046 1 CLAMP, 2.25” WORM GEAR
3 86281180 39298 1 HOSE, 2.0 VAC EXHAUST X 17”
4 86240240 39697 1 HOSE, 3.15 ID X 7.0L VENT
5 86233260 20092 1 CLAMP, 3.5” WORM GEAR
6 86274370 70191 1 SCR, 10-24 X 1/2 HHTC TYPE 23
7 86005810 57245 3 NUT, 1/4-20 HEX NYLOCK SS
8 86010640 87016 1 WASHER, #10 LOCK EXT STAR SS
9 86201970 065-92 3 VAC SPACER 2 1/4 (2 STAGE)
10 86003760 35166 1 GASKET, VAC MTR
11 86296140 - 1 COVER, VAC MOTOR
12 86010630 87013 9 WASHER, 1/4 ID X 5/8 OD SS
13 86007010 70663 3 SCR, 1/4-20 X 3 1/4 HHCS PLT
14 86010670 87029 5 WASHER, 5/16 FLAT SS
15 86277040 70781 5 SCR, 5/16-18 X 1/2 HHCS SS NP
16A 86303840 - 1 VAC MTR, 120V 5.7 2 ST TD 115V
- 86135320 140687 - BRUSH SET, 120V VAC WINDSOR 115V
16B 86304640 - 1 ASSY, VAC MOTOR, 230V 230V
- 86135330 - - BRUSH SET, 230V VAC MTR 230V
