SOLUTION-PUMP
CMPS2 86305210 04/23/08
5-10
REF PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86302790
-
1
HOSE, PULSE, 1/4MSWL X 3/8NPT X
30”
2
86197610
40034
1
HOSEBARB, 3/8MPTX3/8 90D DL
3
86233090
20016
1
CLAMP, 1/4 ID HOSE
4
86302780
-
1
HOSE, BRAIDED, 3/8ID X 16” L
5A
86302820
-
1
PUMP, PUMPTEC, 700PSI
5B
86308100
-
1
PUMP, PUMPTEC, 700PSI, 230V
6
86197540
40013
1
HOSEBARB, 3/8MPT X 1/2 DL
7
86190520
11-800224
4
PLUG, 3/8 SOCHD BR
8
86302770
-
1
HOSE, BRAIDED, 1/2 ID X 14” L
9
86197940
40027
2
HOSEBARB, 3/8MPTX1/2 90D DL
10
86305460
-
1
STRAINER, 3/8 FPT 80 MESH
11
86302760
-
1
HOSE, BRAIDED, 1/2 ID X 4-3/4” L
12
86233150
20042
3
CLAMP, 3/8 HOSE (D-SLOT)
13
86302720
-
1
MOTOR, 700PSI, 115/230 VOLT
14
86302730
-
1
UNLOADER, 800PSI, PUMPTEC
15 86264940 27051
5 CABLE
TIE,
11.38”
UL/CSA
16
86197380
31018
1
ELBOW, 3/8FPT X 1/4FPT
17
86005590
56014
1
NIPPLE, 1/4 CLOSE
18
86197370
31017
1
ELBOW, 1/4FPT X 1/4FPT
19
86302400
-
1
QD, NIPPLE, FOSTER 25MPB
20
86302410
-
2
QD, COUPLER, FOSTER 25FS
