CONTROL PANEL
CMPS2 86305210 04/23/08
5-2
REF PART NO.
PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86233090
20016
3
CLAMP, 1/4 ID HOSE
2
86282280
39634
2
HOSE, 1/4 ID NYLOCBRAID X 23”
3
86232110
270699
2
CAMP CHEM FEED W/DIP TUBE
4
86258930
84187
1
VALVE, CHEMICAL METERING
5
86005700
57104
2
NUT, 10-32 W/STAR WASHER PLTD
6A 86001940 14635 1 BREAKER, 10A CIRUIT
120V
6B 86230110 14312 1 BREAKER,
7A CIRCUIT
230V
7A 86215670 140839 1 BREAKER,
8A VDE CIRCUIT
120V
7B 86230200 14831 1 BREAKER,
5A VDE CIRCUIT
230V
8
86302400
-
1
QD, NIPPLE, FOSTER 25 MPB
9
86197390
31021
1
ELBOW, 1/4 NPT 45D STREET
10
86279560
87178
3
WASHER, 5/8 ID X 1.70 D 0.05T
11
86276290
70626
4
SCR, #10 X 3/4 PPHST HI-LO BLK
12A 86297370
-
1 PANEL,
SWITCH
CONTROL
120V
12B
86302150
-
1
PANEL, 3 SWITCH CONTROL
230V
13
86002450
22015
1
COUPLER, 1/4 QD
14
86002010
14942
2
BOOT, 3/8 CIRCUIT BREAKER
15
86007200
72162
1
SWITCH, DPDT3-POSITION ROCKER
16
86238030
36235
2
GASKET, SWITCH CARLING
17
86007140
72130
1
SWITCH, SPST 2-POSITION ROCKER
18
86310280
-
1
SWITCH, DPST 2 POSITION ROCKER
230V ONLY
