WIRING DIAGRAM – 230V
CMPS2 86305210 04/23/08
5-24
SUGGESTED SPARE PARTS
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86234330 23711 1 CORD ASM, 1.5MM2X 50’ EURO
2 86308770 - 1 HARNESS, MAIN, 230V
3 86307990 - 1 WIRE, 10” GRN/14 76010 X 79010
4 86308750 - 3 WIRE, 4”, BLK/14 76029 X 76029
5 86308760 - 3 WIRE, 4”, BLK/14 76050 X 76029
PART NO. PRV NO. DESCRIPTION
SERIAL
NO.
NOTES:
86241930 47419 KIT, SQUEEGEE TOOL BLADES
86305460 - STRAINER, 3/8FPT 80 MESH
86135320 140687 BRUSH SET, 120V VAC 115V
86028720 53266 VAC MOTOR ASM, 115V W/ TERM 115V
86304640 - ASSY, VAC MOTOR, 230V 230V
86135330 - BRUSH SET, 230V VAC MTR 230V
86002010 14942 BOOT, 3/8 CIRCUIT BREAKER
86215670 140839 BREAKER, 8A VDE CIRCUIT 115V
86001940 14635 BREAKER, 10A CIRCUIT 115V
86230200 14831 BREAKER, 5A VDE CIRCUIT 230V
86230110 14312 BREAKER,7A, CIRCUIT 230V
86241930 47419 KIT, SQUEEGEE TOOL BLADES
86302720 - MOTOR, 700PSI, PUMPTEC
115V &
230V
86302820 - PUMP, PUMPTEC, 115/230 VOLT 115V
86308100 - PUMP, PUMPTEC, 700PSI, 230V 230V
86301880 - SPRAY GUN
86301920 - NOZZLE, ADJUSTABLE, 027 JET
