Electrical Specifications
I
TEM
D
ESCRIPTION
Inputs
1 Analog RGB (Mini D-Sub 15P), 1 Analog RGB R/Cr, G/Y, B/Cb, H, V
(BNC x 5), 1 Digital RGB (DVI-D 24P), 1 Component Y, Cb/Pb, Cr/Pr
(RCA x 3), 1 Component (Mini D-Sub 15P) shared with COMPUTER 1
IN, 1 S-Video (Mini DIN 4P), 1 Video, 3 Stereo Mini Audio, 2
(L/R) RCA Audio
Outputs
1 RGB (Mini D-Sub 15P), 1 Stereo Mini Audio, 1 Screen Trigger
Control
1 PC Control Port (D-Sub 9P)
USB Port
1 B Type (for Service)
LAN Port
RJ-45
Video Compatibility
NTSC, NTSC4.43, PAL, PAL-60/N/M/B/G/H/I), SECAM, HDTV: 1080i, 720p,
SDTV: 576p, 576i, 480p, 480i
Scan Rate
Horizontal: 15 kHz, 31 to 90 kHz (RGB: 31 kHz or over) Vertical: 50 Hz to 85 Hz
Video Bandwidth
RGB: 100 MHz (-3dB)
Color Reproduction
16.7 million colors simultaneously, Full color
Horizontal Resolution
NTSC / NTSC4.43 / PAL / PAL-M / PAL-N / PAL60: 540 TV lines
SECAM: 300 TV lines
RGB: 1024 dots (H) x 768 dots (V)
External Control
RS232, IR, LAN
Sync Compatibility
Separate Sync / Composite Sync / Sync on G
Built-in Speakers
3W x 2
Power Requirement
100 - 240V AC, 50/60Hz
Input Current
7.7A
Power Consumption
655W in Dual Lamp Normal mode / 580W in Dual Lamp Eco mode
350W in Single Lamp Normal mode / 315W in Single Lamp Eco mode
< 30W in Standby mode Normal
< 5W in Standby mode Power saving
