– 9 –
I
TEM
L
ABEL
D
ESCRIPTION
S
EE PAGE
:
10.
POWER SWITCH
Turn on/off the projector
11.
AC IN
Connect the supplied power cable
12.
AUDIO IN [L
(MONO)/R]
(VIDEO)
Connect RCA audio cables (not supplied) from the
input device right and left channels. This audio
jack is shared with S-Video input.
13.
VIDEO IN
Connect a composite video cable (not supplied)
from a video device to the yellow RCA jack
14.
COMPONENT IN (Y,
Pb/Cb, Pr/Cr)
Connect a component video enabled device
15.
COMPUTER 2 IN
(R/Cr, G/Y, B/Cb, H,
V)
Connect RGBHV or Component signal from com-
puter or component video enabled device
16.
COMPUTER 1 IN
Connect a VGA cable (supplied) from a computer
17.
AUDIO IN
(COMPUTER 1)
Connect the audio cable (not supplied) from the input device
18.
LAN
Connect a LAN cable (not supplied) from a computer
19.
SERVICE
Connect the USB cable (not supplied) from a computer. For service
personnel only.
Note:
To use this feature, you must turn on the Screen Trigger function on the OSD.
Screen controllers are supplied and supported by screen manufacturers.
Do not use this jack for anything other than intended use.
