Pin Assignments of Mini D-Sub 15 Pin Input Connector
Signal Levels
Video signal:
0.7Vp-p (Analog)
Sync signal:
TTL level
P
IN
N
UMBER
RGB S
IGNAL
(A
NALOG
)
YC
B
C
R
S
IGNAL
1 Red
Cr
2
Green or Sync on Green
Y
3
Blue
Cb
4 Ground
5 Ground
6
Red Ground
Cr Ground
7
Green Ground
Y Ground
8
Blue Ground
Cb Ground
9
No Connection
10
Sync Signal Ground
11
No Connection
12
Bi-directional DATA (SDA)
13
Horizontal Sync or Composite Sync
14
Vertical Sync
15
Data Clock
