ORANGE BAG
6
BLUE BAG
HARDWARE INCLUDED
10.2 x 22 x 2
Flat Washer
Quantity: 12
M10 Nylon Nut
Quantity: 6
10.2 x 22 x 2
Flat Washer
Quantity: 18
M10 Nylon Nut
Quantity: 7
M10 x 78 Bolt
Quantity: 4
10.2 x 18.4 x 2.5
Lock Washer
Quantity: 5
M10 x 72 Bolt
Quantity: 1
M10 x 62 Bolt
Quantity: 6
M10 x 25 Bolt
Quantity: 1
M10 x 60 Bolt
Quantity: 2
12 x 26 x 2
Flat Washer
Quantity: 1
M6 x 8 Set Screw
Quantity: 4
M10 x 25 Bolt
Quantity: 4
M10 x 65 Bolt
Quantity: 2
5 3 /
4
” Shaft
(illustration not to scale)
Quantity: 1
8 7 /
16
” Axle
(illustration not to scale)
Quantity: 1
