V
AB1
AB5
W
X Z
AA
Y
20
10
STEP
Remove the slotted bolt and nut from one
end. Thread the opposite end, slotted bolt
into the attachment point at the bottom of the
main center upright (AB1) a minimum of 0.5”.
Tighten the nut against the attachment point.
Route the other end through the following
pulleys in the order specified: over the front
of pulley V, under the back of W, over the
back of X, under the back of Y, over the
back of Z, and under the back of floating
pulley AA. Reattach the slotted bolt and nut.
Thread a minimum of 0.5” into the attachment
point on the leg press overhead tube (AB5).
Tighten the nut against the tube. WARNING:
Failure to thread the ends in the specified
distance can result in serious injury!
CABLE #4
