Vision Fitness Multi-Station Gym ST710 - Manual (Page 19)

O
N
P
Q
R
S
T
U
Front
Back
19
9
STEP
Remove the slotted bolt and nut from the end
of the cable. Route this end through the pulleys
in the specified order: thru the center of pulleys
N & O (dual transition pulley assembly),
under P, under Q, over the front of R, under
the back of S (top half of dual floating pulley
assembly), over the back of T, and over the
back of U. Reattach the slotted bolt and nut
to the end of the cable. Thread into the
receiving post of the dual transition pulley
assembly a minimum of 0.5”. WARNING:
failure to thread the end in the specified
distance can result in serious injur y!
CABLE #3
