70 - User's Manual
Media Settings
Click Add Media on the Event Settings page to open the Media Settings page. On this page, you can
specify the type of media that will be sent when a trigger is activated� A total of 5 media settings can be
configured.
Media name: Enter a name for the media setting�
Media Type
There are three media types available: Snapshot, Video Clip, and System log. Select the item to display
the detailed configuration options. You can configure either or all of them.
Snapshot: Select to send snapshots when a trigger is activated�
■ Source: Select to take snapshots from stream 1 or stream 2.
■ Send pre-event images
The Network Camera has a buffer area; it temporarily holds data up to a certain limit� Enter a number
to decide how many images to capture before a trigger is activated� Up to 7 images can be generated�
■ Send post-event images
Enter a number to decide how many images to capture after a trigger is activated� Up to 7 images can
be generated�
For example, if both the Send pre-event images and Send post-event images are set to 7, a total of 15
images are generated after a trigger is activated�
■ File name prefix
Enter the text that will be appended to the front of the file name.
■ Add date and time suffix to the file name
Select this option to append the date/time to the file name.
For example:
Click Save to enable the settings, then click Close to exit the page�
1 pic. 2 pic. 3 pic. 4 pic. 5 pic. 6 pic. 7 pic. 8 pic. 9 pic. 10 pic. 11 pic. 10 pic. 12 pic. 13 pic. 14 pic. 15 pic.
Trigger Activation
Snapshot_ 20080104_100341
Date and time suffix
The format is: YYYYMMDD_HHMMSS
File name prefix
