18 - User's Manual
Live Video Window
■ The following window is displayed when the video mode is set to MPEG-4:
Video Title: The video title can be configured. For more information, please refer to Video Settings on
page 48�
MPEG-4 Protocol and Media Options: The transmission protocol and media options for MPEG-4 video
streaming. For further configuration, please refer to Client Settings on page 21�
Time: Display the current time. For further configuration, please refer to Video Settings on page 48�
Title and Time: The video title and time can be stamped on the streaming video. For further configuration,
please refer to Video Settings on page 48�
Video and Audio Control Buttons: Depending on the Network Camera model and Network Camera
configuration, some buttons may not be available.
Snapshot: Click this button to capture and save still images� The captured images will be displayed
in a pop-up window� Right-click the image and choose Save Picture As to save it in JPEG (*�jpg) or BMP
(*�bmp) format�
Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation. The navigation
screen indicates the part of the image being magnified. To control the zoom level, drag the slider bar. To
move to a different area you want to magnify, drag the navigation screen image.
Pause: Pause the transmission of the streaming media� The button becomes the Resume button
after clicking the Pause button�
Stop: Stop the transmission of the streaming media� Click the Resume button to continue
transmission�
Start MP4 Recording: Click this button to record video clips in MP4 file format� Press the
Stop MP4 Recording button to end recording. When you exit the web browser, video recording stops
accordingly. To specify the storage destination and file name, please refer to MP4 Saving Options on
page 22 for details�
Video and Audio Control Buttons
MPEG-4 Protocol and Media Options
Video Title Time
Title and Time
Video 17:08:56 2008/06/25
