User's Manual - 93
serialnumber
address>
0/7 12 characters MAC address (without hyphens).
firmwareversion string[40] 0/7 Firmware version, including model, company,
and version number in the format:
fwversion string[40] 0/7 ODM-specific firmware version (eg. 210l for
IP7133-SECN ). If there is no specific value, this
field should not be added.
supportscriptversion string[40] 0/7 The version of the supported script language.
scriptversion string[40] 0/7 Current script language version.
webpageversion string[40] 0/7 Current webpage version.
language_count 0/7 Number of webpage languages available on the
server.
language_i<0~(count-1)> string[16] 0/7 Available language lists.
customlanguage_maxcount 0/7 Maximum number of custom languages
supported on the server.
customlanguage_count 0/7 Number of custom languages which have been
uploaded to the server.
customlanguage_i<0~(max
count-1)>
string 0/7 Custom language name.
Group: status
NAME VALUE SECURITY
(get/set)
DESCRIPTION
videoactualmodulation ntsc,
pal
4/7 The actual modulation type
(videoin.type=0).
di_i<0~(ndi-1)> 1/7 0 => Inactive, normal
1 => Active, triggered
do_i<0~ndi-1)> 1/7 0 => Inactive, normal
1 => Active, triggered
onlinenum_rtsp integer 6/7 Current number of RTSP connections.
onlinenum_sip integer 6/7 Current number of SIP connections.
onlinenum_httppush integer 6/7 Current number of HTTP push server connections.
eth_i0 1/99 Get network information from mii-tool.
Group: di_i<0~(ndi-1)> (capability.ndi > 0)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
normalstate high, 1/1 Indicates open circuit or closed circuit
