VIVOTEK - A Leading Provider of Multimedia Communication Solutions

User's Manual - 35

4. In the Networking Services dialog box, select

Universal Plug and Play and click OK�

5� Click

Next in the following window�

6� Click

Finish� UPnP

is enabled�

► How does UPnP

work?

UPnP

networking technology provides automatic IP configuration and dynamic discovery of devices

added to a network. Services and capabilities offered by networked devices, such as printing and file

sharing, are available to each other without the need for cumbersome network configuration. In the

case of Network Cameras, you will see Network Camera shortcuts under My Network Places.

► Enabling UPnP port forwarding allows the Network Camera to open a secondary HTTP port on the

router-not HTTP port-meaning that you will need to add the secondary HTTP port number to the

Network Camera’s public address in order to access the Network Camera from the Internet� For

example, when the HTTP port is set to 80 and the secondary HTTP port is set to 8080, refer to the list

below for the Network Camera’s IP address�

From the Internet

LAN

http://203.67.124.123:8080

http://192.168.4.160 or

http://192.168.4.160:8080

► If the PPPoE settings are incorrectly configured or Internet access is not working, restore the Network

Camera to factory default; please refer to Restore on page 79 for details� After the Network Camera is

reset to factory default, it will be accessible on the LAN.
