Operation
46 Vidikron Vision 50 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
Main Menu The Main Menu is the starting point for accessing all projector functions.
(The Service and ISF Calibration menus are hidden and not accessible until you enter a
passcode.)
Picture Adjust Select Picture Adjust from the Main Menu to calibrate your Vision 50 for optimum picture
quality.
To adjust a setting, use the or button to highlight it and use the or button to
change the setting. When finished, press EXIT.
The Vision 50 has been designed to incorporate setup and calibration standards established
by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted,
industry-recognized standards for optimal video performance and has implemented a
training program for technicians and installers to use these standards to obtain optimal
picture quality from Vidikron video display devices. Accordingly, Vidikron recommends that
setup and calibration be performed by an ISF certified installation technician.
All signal types require separate processing. Therefore, you need to calibrate each input
separately.
Vision Model 50
Picture Adjust
Image Option
Projector Status
Installation
Service
ISF Calibration
➤
Picture Adjust
Brightness 30
Contrast 15
Color 31
Tint 15
Sharpness 2
Color Temp. 2
Color Select NTSC
➤
When you change a picture quality setting, save the change to a preset
afterwards. Otherwise, the change will be lost when a different input is
selected. (Picture quality settings are saved for each input and resolution
separately.) For information about saving settings, refer to Save
Settings on page 54.
Note
