VistaQuest N7227V5 User Manual
Page 42
– 42 –
Output Relay Displays
Enter Relay No.
(00 = Quit)
01
Upon pressing
✱
80, this screen will appear. Enter the Relay Number 01, 02,
03, or 04 for a 4204 (or 00 to end these entries). Press the [
✱
] key to
continue.
The [
✱
] key is used to accept an entry and advance to the next prompt. The
[#] key is used to revert back to the last question to check or change an
entry. Press [
✱
] to go forward again.
02 A EV ZL ZT
STT
0 0 0
00
This screen displays a summary of the current Relay START programming
(for this example, relay 02 has been selected).
Press the [
✱
] key to continue.
02 A EV ZL ZT
STP – – 0 00
This screen displays a summary of the current Relay STOP programming.
Press the [
✱
] key to continue.
02 Relay Action
No Response
0
Enter the desired relay action as listed below. Press the [
✱
] key to continue.
0 = No response
2 = Close and Stay Closed
1 = Close for 2 seconds
3 = Continuous Pulse on & off
( 1 sec ON, 1 sec OFF)
02 Start Event
Not Used
0
Enter the event to START the relay:
0 = Not used; 2 = Fault; 1 = Alarm; 3 = Trouble
A zone list must be used in conjunction with an event. If a zone type/system
operation is to be used instead of an event, enter 0.
Press the [
✱
] key to continue.
02 Start:
Zn List
No List
0
If a zone list will be used to START the relay action, enter the zone list number
(to be programmed in field
✱
81): 1, 2, or 3. If not used, enter 0. Press the [
✱
]
key to continue.
02 Start:
Zn Typ
Not Used
00
If a zone type or system operation will be used to START the relay action,
enter the appropriate two-digit code (see table that follows). If not, enter 00.
Press the [
✱
] key to continue.
CHOICES FOR ZONE TYPES
00 = Not Used
05 = Trouble Day/Alarm Night 08 = 24 Hr Aux
01 = Entry/Exit
06 = 24 Hr Silent
09 = Fire
03 = Perimeter
07 = 24 Hr Audible
10 = Interior w/Delay
04 = Interior Follower
CHOICES FOR SYSTEM OPERATION
20 = Arming–Stay
33 = Any Burglary Alarm
39 = Any Fire Alarm
21 = Arming–Away
34 = Code + # + 7 Key Entry
40 = Bypassing
22 = Disarming (Code + OFF)
35 = Code + # + 8 Key Entry
41 = AC Power Failure
31 = End of Exit Time
36 = At Bell Timeout**
42 = System Batt. Low
32 = Start of Entry Time
38 = Chime
58 = Duress
**Or at Disarming, whichever occurs earlier.
02 Stop:
Zn List
No List
0
If a zone list will be used to STOP, or restore, the relay action, enter the zone list
(ZL) number 1, 2, or 3 (to be programmed in
✱
81 mode). If not used, enter 0.
Press the [
✱
] key to continue.
02 Stop:
Zn Typ
Not Used
00
If a zone type or system operation will be used to STOP the relay action, enter
the appropriate two digit code (see the "ZT" choices listed above). If not, enter
00. Press the [
✱
] key to continue.
02 A EV ZL ZT
STT 0 0 0 00
This screen again displays a summary of the current relay START
programming.
Press the [
✱
] key to continue.
02 A EV ZL ZT
STP – – 0 00
This screen again displays a summary of the current relay STOP programming.
Press the [
✱
] key to continue.
