PARTS LIST
LOG BASE ASSEMBLY
THERMOSTAT-CONTROLLED MODELS
VSGF28PTC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 23 of this manual.
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
104388-02
Front Log (#1)
1
2
104390-02
Middle Log (#2)
1
3
104392-02
Rear Log (#3)
1
4
104394-02
Crossover Log (#4)
1
5
098304-01
Screw, #10 Phillips, Black
8
6
104286-01
ODS Pilot
1
7
098249-01
Nut
4
8
101006-02
Pilot Bracket
1
9
101330-05
Front Burner Assembly
1
10
100999-02
Rear Burner Assembly
1
11
102257-08CJ
Base Assembly
1
12
098271-06
Ignitor Cable
1
13
103410-01CK
Firebox Bottom
1
14
098867-10
Gas Regulator
1
15
101004-01
Front Burner Injector
1
16
102845-01
Inlet Tube
1
17
101382-01
Thermovalve Bracket
1
18
099387-03
Pilot Tube
1
19
102846-01
Burner Tube
1
20
097809-02
Adapter
1
21
099211-01
Screw
2
22
098544-01
Thermostat Clamp
1
23
101329-18
Thermostat Gas Valve Assembly
1
24
101381-01
Cover and Piezo
1
25
101004-15
Rear Burner Injector
1
26
M11084-26
Hex Screw, #10
2
27
101628-03
Flex Hose
1
28
M11084-38
Screw
2
29
901063-01
3/8" Flare x 1/2" NPT
1
PARTS AVAILABLE — NOT SHOWN
100563-01
Warning Plate
1
101054-01
Lighting Instructions Plate
1
100565-01
Warning Plate Fastener
1
PARTS LIST
VSGF28PTC
