PARTS LIST
FIREPLACE
VSGF28PVA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 23 of this manual.
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
101357-01
Top Outer Casing
1
2
**
Outer Casing
1
3
102758-02CK
Right Front Side
1
4
102759-02CK
Left Front Side
1
5
098304-01
Phillips Pan Head Screw, #10
17
6
101351-01CK
Top Front
1
7
102455-02
Louver Extruded
2
8
101353-01CK
Middle Front Rail
1
9
101712-02
Firebox Hood
1
10
101348-01
Firebox Support
2
11
099230-01
Shoulder Screw
4
12
101872-03
Firebox Top
1
13
101346-01
Outer Base
1
14
**
Firebox Wrapper
1
15
101514-01
Cover
1
16
M11084-26
Hex Screw, #10
57
17
098304-03
Phillips Pan Head Screw, #8
4
18
101727-03
Screen Assembly
1
PARTS AVAILABLE — NOT SHOWN
099038-01
Strain Relief Bushing
1
100639-01
Caution Decal
1
103590-01
Decal Strip
1
104313-01
Hinge, Pin
1
104313-02
Hinge, Pin
1
M10908-2
Screw, Slotted Hex Head Tapping
4
** Not a field replaceable part.
PARTS LIST
VSGF28PVA
