OPERATING FIREPLACE
Continued
Locate the blower switch by opening lower louver on fireplace.
Blower switch is located at lower left inside louver door.
This thermostat-controlled blower has a variable speed control
with an ON/OFF switch. The blower will start when the
thermostat senses a sufficient increase in firebox temperature.
Note: It is safe to operate fireplace with blower turned off. However,
the blower helps distribute heated air from the fireplace.
MODEL VSGF28PV
Blower Kit Model GA3750 Series
This optional non-thermostat blower kit features a variable
control which allows you to select the speed you desire. After
about 15 minutes, turn the blower on to deliver heated air at the
top louvers.
IMPORTANT: Light your gas appliance with the blower off.
Note: Periodically check the louvers of the firebox and remove
any dust, dirt, or other obstructions.
Follow installation instructions included with the blower accessory.
Blower Kit Model GA3650T Series
Locate the blower switch by opening the lower louver on fire-
place. Blower switch is located at lower left inside louver door.
The GA3650T thermostat-controlled blower has a variable
speed control with an ON/OFF switch. The blower will start
when the thermostat senses a sufficient increase in firebox
temperature.
IMPORTANT: Light your gas appliance with the blower off.
Note for GA3650T: If you are using GA3650T blower, your gas
fireplace and blower will not turn on and off at the same time.
The fireplace may run for several minutes before the blower
turns on. After the heater modulates to the pilot position, the
blower will continue to run. The blower will shut off after the
firebox temperature decreases.
Note: It is safe to operate fireplace with blower turned off.
However, the blower helps distribute heated air from the fire-
place.
Note: Periodically check the louvers of the firebox and remove
any dust, dirt, or other obstructions.
Follow installation instructions included with the blower
accessory.
BLOWER OPERATION
WARNING: This fireplace has a three-prong,
grounded electrical plug. This plug helps protect you
against electrical shock. Only connect plug to a
properly grounded, three-prong receptacle. Do not
cut or remove the grounding prong from this plug.
MODEL VSGF28PTC
TO TURN OFF GAS
TO APPLIANCE
WARNING: Do not operate heater between locked
positions.
CAUTION: Do not try to adjust heating levels by
using the equipment shutoff valve.
The variable control valve can be set to any heat setting and flame
height desired, by simply turning the control knob until that setting
is attained. Even the lowest setting provides realistic flames and
glowing embers from two burners. Selecting higher settings pro-
duces greater heat output. This results in increased heating comfort.
Shutting Off Fireplace
1. Turn control knob clockwise
Clockwise
to the HIGH position.
2. Slightly depress control knob and turn clockwise
Clockwise
to the PILOT position.
3. Slightly depress control knob and turn clockwise
Clockwise
to the OFF position.
Shutting Off Burners Only (pilot stays lit)
1. Turn control knob clockwise
Clockwise
to the HIGH position.
2. Press in and turn clockwise
Clockwise
to the PILOT position.
VARIABLE CONTROL
OPERATION
MANUAL LIGHTING
PROCEDURE
1. Follow steps 1 through 5 under Lighting Instructions, page 16.
2. Depress control knob and light pilot with match.
3. Keep control knob pressed in for 30 seconds after lighting
pilot. After 30 seconds, release control knob. Now follow
step 8 under Lighting Instructions, page 16.
OPERATING FIREPLACE - Manually-Controlled Models
Variable Control Operation
To Turn Off Gas to Appliance
Manual Lighting Procedure
Blower Operation
