PARTS LIST
LOG BASE ASSEMBLY
VARIABLE MANUALLY-CONTROLLED
MODELS
VSGF28PVA
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 23 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 104388-02 Front Log (#1) 1
2 104390-02 Middle Log (#2) 1
3 104392-02 Rear Log (#3) 1
4 104394-02 Crossover Log (#4) 1
5 098304-01 Screw, #10 Phillips, Black 8
6 107486-01 ODS Pilot 1
7 098249-01 Nut 6
8 101006-02 Pilot Bracket 1
9 101330-05 Front Burner Assembly 1
10 100999-02 Rear Burner Assembly 1
11 102257-08CJ Base Assembly 1
12 098271-06 Ignitor Cable 1
13 103410-01CK Firebox Bottom 1
14 098867-10 Gas Regulator 1
15 101004-01 Front Burner Injector 1
16 102445-01 Piezo Ignitor 1
17 101007-01 Crossover Tube 1
18 099387-05 Pilot Tube 1
19 101972-01 Valve and Piezo Bracket 1
20 M11084-38 Regulator Hex Screw 2
21 102668-01 Front Burner Tube 1
22 101008-01 Gasket 1
23 101973-01 Inlet Tube 1
24 098276-01 1/8" Plug 1
25 101004-15 Rear Burner Injector 1
26 M11084-26 Hex Screw, #10 2
27 098508-01 Valve Retainer Nut 1
28 101628-03 Flex Hose 1
29 097809-02 Adapter 1
30 098354-01 Control Knob 1
31 102568-02 Control Valve 1
32 901063-01 3/8" Flare x 1/2" NPT 1
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
101055-02 Lighting Instructions Plate 1
100565-01 Warning Plate Fastener 1
101976-02 Control Position Decal 1
PARTS LIST
VSGF28PVA
