SVM2608 Programming 29
OFFSET WRITE FUNCTION READ FUNCTION
0x56 Reserved Result Register (Channel 1) – (LS)
0x58 Control (Channel 2) Control (Channel 2)
0x5A Trigger Level (Channel 2) Trigger Level (Channel 2)
0x5C Sample Rate (Channel 2) – (MS) Sample Rate (Channel 2) – (MS)
0x5E Sample Rate (Channel 2) – (LS) Sample Rate (Channel 2) – (LS)
0x60 Sample Points (Channel 2) – (MS) Sample Points (Channel 2) – (MS)
0x62 Sample Points (Channel 2) – (LS) Sample Points (Channel 2) – (LS)
0x64 Pre-Trigger Points (Channel 2) – (MS) Pre-Trigger Points (Channel 2) – (MS)
0x66 Pre-Trigger Points (Channel 2) – (LS) Pre-Trigger Points (Channel 2) – (LS)
0x68 Trigger Delay (Channel 2) – (MS) Trigger Delay (Channel 2) – (MS)
0x6A Trigger Delay (Channel 2) – (LS) Trigger Delay (Channel 2) – (LS)
0x6C Timeout (Channel 2) Timeout (Channel 2)
0x6E Interrupt Enable (Channel 2) Interrupt Enable (Channel 2)
0x70 Reserved Interrupt Status (Channel 2)
0x72 Command Register (Channel 2) Command Register (Channel 2)
0x74 Reserved FIFO Data (Channel 2) – (MS)
0x76 Reserved FIFO Data (Channel 2) – (LS)
0x78 Reserved Result Register (Channel 2) – (MS)
0x7A Reserved Result Register (Channel 2) – (LS)
0x7C Reserved Result Register (Channel 2) – (MS)
0x7E Reserved Result Register (Channel 2) – (LS)
0x80 Control (Channel 3) Control (Channel 3)
0x82 Trigger Level (Channel 3) Trigger Level (Channel 3)
0x84 Sample Rate (Channel 3) – (MS) Sample Rate (Channel 3) – (MS)
0x86 Sample Rate (Channel 3) – (LS) Sample Rate (Channel 3) – (LS)
0x88 Sample Points (Channel 3) – (MS) Sample Points (Channel 3) – (MS)
0x8A Sample Points (Channel 3) – (LS) Sample Points (Channel 3) – (LS)
0x8C Pre-Trigger Points (Channel 3) – (MS) Pre-Trigger Points (Channel 3) – (MS)
0x8E Pre-Trigger Points (Channel 3) – (LS) Pre-Trigger Points (Channel 3) – (LS)
0x90 Trigger Delay (Channel 3) – (MS) Trigger Delay (Channel 3) – (MS)
0x92 Trigger Delay (Channel 3) – (LS) Trigger Delay (Channel 3) – (LS)
0x94 Timeout (Channel 3) Timeout (Channel 3)
0x96 Interrupt Enable (Channel 3) Interrupt Enable (Channel 3)
0x98 Reserved Interrupt Status (Channel 3)
0x9A Command Register (Channel 3) Command Register (Channel 3)
0x9C Reserved FIFO Data (Channel 3) – (MS)
0x9E Reserved FIFO Data (Channel 3) – (LS)
0xA0 Reserved Result Register (Channel 3) – (MS)
0xA2 Reserved Result Register (Channel 3) – (LS)
0xA4 Reserved Result Register (Channel 3) – (MS)
0xA6 Reserved Result Register (Channel 3) – (LS)
0xA8 Control (Channel 4) Control (Channel 4)
0xAA Trigger Level (Channel 4) Trigger Level (Channel 4)
0xAC Sample Rate (Channel 4) – (MS) Sample Rate (Channel 4) – (MS)
0xAE Sample Rate (Channel 4) – (LS) Sample Rate (Channel 4) – (LS)
0xB0 Sample Points (Channel 4) – (MS) Sample Points (Channel 4) – (MS)
0xB2 Sample Points (Channel 4) – (LS) Sample Points (Channel 4) – (LS)
0xB4 Pre-Trigger Points (Channel 4) – (MS) Pre-Trigger Points (Channel 4) – (MS)
