SVM2608 Introduction 21
O PTION 1 - SVM2608-01
N UMBER OF C HANNELS
2
VME BUS I NTERFACE
Address Mode
Data Transfer Mode A32
D16 or D32
S AMPLING R ATE
Range
Resolution
Accuracy 7.15 Samples/s to 20.0 MSamples/s
8.333 ns
1%
M EMORY
1 MSamples per channel
V OLTAGE M EASUREMENTS
Range
Resolution
Accuracy ±0.5 V, ±1.0 V, ±2.0 V, ±5.0 V, ±10.0 V, ±20.0 V
Range/2
11
1%
I NPUT I MPEDANCE
1 MΩ or 50 Ω (software selectable)
I NPUT M ODE
ac or dc (software selectable)
I NPUT F ILTER
5 MHz (-3 dB)
T RIGGER L EVELS
Internal
Range
Trigger level resolution
Level accuracy
External
Range
Trigger level resolution
Level accuracy
trigger level determined by selected voltage range (see Voltage Measurement above)
Full scale/2
11
1%
-10 V to +10 V
4.88 mV
1%
D ELAYED T RIGGER
Range
Resolution 0 samples to (2 24 -1) samples
1 sample
T RIGGER A CCURACY
1%
E XTERNAL T RIGGER A CCURACY
1%
T IMEOUT
Range
Resolution 10 µs to 227 hrs
10 µs to 100 s
W ARM - UP T IME
10 min
MTBF
80,000 hrs (based on 20% Ground Mobile, 80% Ground Fixed environment, T ≥ 52°C)
