VXI Technology, Inc.
28 SVM2608 Programming
T
ABLE
3-1: SVM2608 A32 R
EGISTER
M
AP
Note
MS = Most Significant LS = Least Significant
OFFSET WRITE FUNCTION READ FUNCTION
0x00 Sysfail Control, Interrupt Levels Sysfail Control, Interrupt Levels
0x02 Force Trigger/Start Force Trigger/Start
0x04 Reserved Reserved
0x06 External Trigger Level External Trigger Level
0x08 Control (Channel 0) Control (Channel 0)
0x0A Trigger Level (Channel 0) Trigger Level (Channel 0)
0x0C Sample Rate (Channel 0) – (MS) Sample Rate (Channel 0) – (MS)
0x0E Sample Rate (Channel 0) – (LS) Sample Rate (Channel 0) – (LS)
0x10 Sample Points (Channel 0) – (MS) Sample Points (Channel 0) – (MS)
0x12 Sample Points (Channel 0) – (LS) Sample Points (Channel 0) – (LS)
0x14 Pre-Trigger Points (Channel 0) – (MS) Pre-Trigger Points (Channel 0) – (MS)
0x16 Pre-Trigger Points (Channel 0) – (LS) Pre-Trigger Points (Channel 0) – (LS)
0x18 Trigger Delay (Channel 0) – (MS) Trigger Delay (Channel 0) – (MS)
0x1A Trigger Delay (Channel 0) – (LS) Trigger Delay (Channel 0) – (LS)
0x1C Timeout (Channel 0) Timeout (Channel 0)
0x1E Interrupt Enable (Channel 0) Interrupt Enable (Channel 0)
0x20 Reserved Interrupt Status (Channel 0)
0x22 Command Register (Channel 0) Command Register (Channel 0)
0x24 Reserved FIFO Data (Channel 0) – (MS)
0x26 Reserved FIFO Data (Channel 0) – (LS)
0x28 Reserved Result Register (Channel 0) – (MS)
0x2A Reserved Result Register (Channel 0) – (LS)
0x2C Reserved Result Register (Channel 0) – (MS)
0x2E Reserved Result Register (Channel 0) – (LS)
0x30 Control (Channel 1) Control (Channel 1)
0x32 Trigger Level (Channel 1) Trigger Level (Channel 1)
0x34 Sample Rate (Channel 1) – (MS) Sample Rate (Channel 1) – (MS)
0x36 Sample Rate (Channel 1) – (LS) Sample Rate (Channel 1) – (LS)
0x38 Sample Points (Channel 1) – (MS) Sample Points (Channel 1) – (MS)
0x3A Sample Points (Channel 1) – (LS) Sample Points (Channel 1) – (LS)
0x3C Pre-Trigger Points (Channel 1) – (MS) Pre-Trigger Points (Channel 1) – (MS)
0x3E Pre-Trigger Points (Channel 1) – (LS) Pre-Trigger Points (Channel 1) – (LS)
0x40 Trigger Delay (Channel 1) – (MS) Trigger Delay (Channel 1) – (MS)
0x42 Trigger Delay (Channel 1) – (LS) Trigger Delay (Channel 1) – (LS)
0x44 Timeout (Channel 1) Timeout (Channel 1)
0x46 Interrupt Enable (Channel 1) Interrupt Enable (Channel 1)
0x48 Reserved Interrupt Status (Channel 1)
0x4A Command Register (Channel 1) Command Register (Channel 1)
0x4C Reserved FIFO Data (Channel 1) – (MS)
0x4E Reserved FIFO Data (Channel 1) – (LS)
0x50 Reserved Result Register (Channel 1) – (MS)
0x52 Reserved Result Register (Channel 1) – (LS)
0x54 Reserved Result Register (Channel 1) – (MS)
