Basic setup, Lear ning method – Universal Remote Control (URS) RF30 User Manual

Page 10

background image

17

18

Lear

ning Method

BASIC SETUP

Lear

ning Method

BASIC SETUP

STEP 5:

Press any button on the RF30
that you want to teach a
command to. The top of the
screen will change to "READY"
and the bottom of the screen will
display the button you pressed.

STEP 6:

Press and hold the button on the
other remote control that you
want to ‘teach’ to the RF30 until
the LCD display on the RF30
changes to either “GOOD” or
“FAILD”. If the “GOOD” label
appears on top of the display
and “SAVED” flashes on the bot-
tom, you were successful. If
the “FAILD” label appears on
top of the display, try ‘teaching’
the same button to the RF30
once again by repeating STEPS
5 and 6.

STEP 7:

Now, continue to teach the RF30
any other commands from your
old remotes by repeating STEPS
4 through 6 (to go back to STEP
4, simply press MAIN once).

STEP 8:

Once you have completed
teaching all the button
commands to the RF30, return to
normal operation by pressing the
MAIN button twice.

Test all your new commands. If
any of them don’t work, try the
Learning Method again, follow-
ing these suggestions:

• Move to another room. Plasma

TVs, sunlight, halogen or quartz
lighting can interfere with the
learning process.

• Even though the old remote

seems to be working fine, put in
fresh alkaline batteries.

• Gradually vary the distance

between the remote controls.

Try 1”, 2” and so on, up to
4 feet.
• Try tapping the button on your

old remote instead of pressing
and holding it during the
learning process.

Some additional Information
regarding the Learning Process:

• Learned functions override any

existing pre-programmed
functions on the remote control.

• All buttons can be learned

except for the PAGE, MAIN and
LIGHT buttons.

• Learned functions are

automatically erased when a
new function is learned on the
same button.

• Learned functions are retained

even after a different Setup
Code Number is programmed
into the remote.

• To return to an original pre-

programmed function, a learned
function must be erased.

NOTE: If you don’t see the display button
you would like to teach on the LCD
screen, use the (

or ) PAGE buttons at

the bottom of the screen.The only
buttons you can’t teach are the PAGE and
MAIN buttons.
