6.
Technical Specifications
This section provides the specifications of SmartGST801M and the
following table lists these specifications.
Specifications
Standards
Compliance
IEEE 802.3u 100Base- FX Fast Ethernet
IEEE 802.3z Gigabit Fiber
Protocol CSMA/CD
Max Forwarding
and
Max Filtering Rate
14,8800 pps per Fast Ethernet port,
148,8000 pps per Gigabit Ethernet port (GBIC)
LED Indicators Fiber Ports: LINK/ACTIVE, Full Duplex/Collision
(100Mbps Fiber port); Link/Active (GBIC port)
Per Unit: Power
Fiber Link
Maximum Distance
SC/ST Multi-mode:
Half-duplex: 412m, Full-duplex: 2Km
SC Single Mode:
Half-duplex: 412m, Full-duplex: 30Km
Dimensions 440mm x 160mm x 44mm (L x W x H)
Weight 2200g ±40 g
Storage Temp. -40…C to 70…C ( -40…F to 158…F)
Operational Temp. 0…C to 45…C ( 32…F to 1 13…F )
Operational
Humidity
10% to 90% (Non-condensing)
External Power 100-240V AC, 50-60Hz
Power
Consumption
17 Watts ( Max )
EMI FCC Class A, CE Mark
Safety UL, cUL
